What hub heights and spans does this jib crane come in?
This PM-Series jib crane is offered in hub heights from 8 ft to 20 ft, in 2 ft increments, and spans from 10 ft to 16 ft, also in 2 ft increments. That gives 28 model combinations, from PM108-10 (8 ft hub, 10 ft span) up to PM120-16 (20 ft hub, 16 ft span), so you can match it to your ceiling height and reach requirement.
What is the capacity across these models?
All models in this PM-Series line are rated at 1/2 ton capacity. The capacity stays the same across every hub height and span combination listed; only the physical dimensions and unit weight change as you go up in size.
How much does the crane itself weigh?
Weight increases with hub height and span. The smallest configuration, PM108-10 (8 ft hub, 10 ft span), weighs 630 lbs, while the largest, PM120-16 (20 ft hub, 16 ft span), weighs 1,157 lbs. Use the weight for your specific model number when planning foundation, anchoring, or freight handling.
How do I pick the right model number for my facility?
Match the hub height to your usable ceiling clearance and the span to how far the load needs to reach from the pillar. For example, PM112-14 gives a 12 ft hub height with a 14 ft span at 834 lbs unit weight, while PM118-10 gives an 18 ft hub height with a shorter 10 ft span at 905 lbs. Pick the combination closest to your building dimensions.
Does a taller hub height always mean a heavier unit?
Yes, within a given span, weight increases as hub height increases. For a 10 ft span, weight rises from 630 lbs at 8 ft hub (PM108-10) to 947 lbs at 20 ft hub (PM120-10). The same pattern holds for the 12 ft, 14 ft, and 16 ft span options.
