EKKO EB13E | Electric Straddle Stacker | 119" Lift Height | 2800 lb Capacity

See more by EKKO

$588.90 Off Limited time deal

$5,888.00

$5,888.00 - $5,888.00

$5,888.00

$5,299.10

$5,299.10 - $5,299.10

$5,299.10

In stock

SKU EB13E

Quantity

Product Overview

In short

The EKKO EB13E is a walk-behind electric straddle stacker with a 2800 lb load capacity and a maximum lift height of 119 inches. It combines features of a forklift, reach truck, and walkie stacker, making it suited for warehouse, stockroom, and distribution facility operations.

The EKKO EB13E Electric Straddle Stacker is an all-in-one, high-productivity, versatile material-handling solution that can be used to handle pallets from the floor to the top of racking systems in warehouse environments, stockrooms and distribution centers. The EKKO EB13E has a 2800-lb load capacity and a maximum lift height of 119 inches which will help you safely stack pallets and maximize your vertical storage space usage. The straddle leg design of the EKKO EB13E also helps with pallet stacking by giving you additional stability and allowing for better pallet engagement; this is very helpful when handling many different types and configurations of pallets. The fully electric lift and drive on the EKKO EB13E provide smooth, efficient travel, precise lifting control and consistent performance day after day, while minimizing physical labor and fatigue for the operator. The compact size and maneuverability of the EKKO EB13E makes it suitable for use in tight spaces such as narrow aisles and crowded working conditions; it gives you the ability to productively and safely operate the unit every day.

Key Features

2800 lbs load capacity for safely lifting and stacking pallets

119 inch maximum lift height for maximizing rack stacking and vertical storage space

Straddle Leg Design for added stability and versatility when moving and handling pallets

All-Electric Drive and Lift for a productive, low-maintenance daily material handling operation

Compact Size and Maneuverability for operation in small aisles and tight working spaces

Specification Table

EB13E · Full Electric Pallet StackerSKU EB13E
Load capacity	2800 (lbs)
The max. lifting height	119” (in)
Load center distance	24 (in)
Fork length	45.3 (in)
Single fork width	4 (in)
Overall fork width	8.3-33.5 (in)
Lowered fork height	2.35 (in)
Fixed leg length	36.5 (in)
Adjustable legs	45.5-59.1 (in)
Turning radius	52.6 (in)
Overall length	70 (in)
Max Overall width	61 (in)
Extended mast height	135 (in)
Lowered mast height	82 (in)
Battery voltage (dimensions)	24V/50Ah Lithium (in)
Internal Charger	24V/15A V/A
Lifting Motor	2.2kw. Lift speed, laden/unladen:92/136mm/s Lowering speed, laden/unladen:112/98mm/s V/Kw
Driving Motor	0.75kw.Driving speed: laden/unladen:4.0/4.2km/h
Service Weight	1325 (lbs)
Brand / Model	EKKO EB13E
Stacker Design	Straddle Leg
Power Source	Electric
Maximum Lift Height	119 in (Approx. 3023 mm)
Operation Style	Walk-Behind
Drive System	Electric Drive
Lift System	Electric Lift
Primary Applications	Warehouse, Stockroom, Distribution Facilities

FAQ about this model

What is the maximum load capacity and at what load center?

The EB13E carries up to 2800 lbs with a 24 in load center. If your pallets are heavier or the load center is longer than 24 in, the actual safe capacity will be lower than the rated 2800 lbs, so check your load dimensions before ordering.

Will this stacker fit through my aisles and around standard pallets?

The straddle legs adjust from 45.5 in to 59.1 in wide to fit different pallet types, with a fixed leg length of 36.5 in. Overall unit width is 61 in max, overall length is 70 in, and the turning radius is 52.6 in, so measure your aisle width against those figures.

What powers the EB13E and how is it charged?

It runs on a 24V/50Ah lithium battery with a built-in 24V/15A internal charger. The lifting motor is 2.2kW and the drive motor is 0.75kW, giving laden/unladen lift speeds of 92/136 mm/s and drive speeds of 4.0/4.2 km/h.

How is the EB13E operated?

It's a walk-behind, straddle-leg design with electric drive and electric lift, meaning the operator walks alongside the unit to steer rather than riding on it. Lowering speeds are 112/98 mm/s laden/unladen, and forks lower to 2.35 in for pallet entry.

How much does the unit itself weigh, and what's the lift height?

Service weight is 1325 lbs. Maximum lift height is 119 in with the mast extended to 135 in, and the mast retracts to 82 in when lowered — worth checking against your ceiling or doorway clearance.

What settings is this stacker designed for?

EKKO lists this model for warehouse, stockroom, and distribution facility use. Its straddle-leg frame and 2800 lb capacity suit palletized loads on flat, hard floors typical of those environments rather than rough outdoor terrain.

Compare models

	4400 Electric Straddle Stacker 216"	4400 Electric Straddle Stacker 177"	2800 Electric Straddle Stacker 119" THIS
Capacity	4400 (lb)	4400 (lb)	2800 (lbs)
Fixed leg length	42 (in)	42 (in)	36.5 (in)
Forks	45.28 (in)	45.3 (in)	45.3 (in)
Lift Height	216 (in)	177 (in)	119” (in)
Price	$17,278.00 $16,414.10	$16,502.00 $15,676.90	$5,888.00 $5,299.10
	Check ›	Check ›	Viewing

Specs from EKKO manufacturer data. Prices update live and reflect current promotions.
