Product Overview

In short

The Katool KT-M140XD is a 2-post overhead automotive lift with a 14,000 lb rated lifting capacity, built for raising larger vehicles during service and repair.

Overview

The Katool KT-M140XD is a 2-post overhead car lift with a 14,000 lb rated capacity. Its two-post design provides open access to the underbody, making it well suited to servicing heavier vehicles in professional and serious home workshops.

Working within the capacity

To use the lift safely, balance the load across both posts and arms. A simple way to check is to calculate the front axle weight by subtracting the rear axle weight from the total vehicle weight, then determine arm capacity by dividing each axle's weight by two to find the load per arm. Always adhere to the lift's weight limits and never exceed its total or per-arm capacities.

Key features

14,000 lb capacity for lifting heavier vehicles
2-post overhead design with an open underbody for full service access
Per-arm load balancing so weight can be distributed evenly across the arms
Capacity-first operation — confirm axle and per-arm loads before lifting
Authorized Katool dealer — sold and supported by Vovlift

Specification Table

KT-M140XD · 2-Post Car LiftSKU KT-M140XD
Lifting Capacity	14,000 lbs
Maximum Lifting Height	73″ (1800 mm)
Overall Height	167″
Overall Width	158″
Drive-Thru Clearance	133″
Motor Power	4 HP
Power Supply	220V / 1 Phase
Construction Material	Alloy Steel
Net Weight	2,050 lbs (930 kg)
Shipping Weight	1,960 lbs
Drive System	Direct-Drive (No Chain)
Lock Release	Single-Point
Arm Configuration	Symmetric
Column Design	Dual S-Column Reinforced

Compare models

	KT-4H850 Katool 8,500 lb	KT-CT330 330 lb Manual Table	KT-X99 Katool Full Rise	KT-PMRL200 Katool Portable Two-Post	KT-M140XD Katool 14,000 lb THIS
Price	$3,199.00 $2,699.00	$439.00	$4,499.00	$2,599.00	$3,699.00
	Check ›	Check ›	Check ›	Check ›	Viewing

Specs from Katool manuals. Prices update live and reflect current promotions.

FAQ about this model

What is the lifting capacity of the KT-M140XD?
It has a rated lifting capacity of 14,000 lb.

What type of lift is this?
It is a 2-post overhead automotive car lift.

How do I make sure a vehicle is within the lift's limits?
Calculate the front axle weight by subtracting the rear axle weight from the total vehicle weight, then divide each axle's weight by two to find the load per arm. Never exceed the lift's total or per-arm weight capacities.

How is the load distributed on a 2-post lift?
The vehicle's weight is supported across both posts and their arms, so the load should be balanced and kept within the per-arm capacity.

Is this lift suitable for heavier vehicles?
Yes. With a 14,000 lb rated capacity, it is intended for lifting larger and heavier vehicles, provided they stay within the rated total and per-arm limits.

Is the KT-M140XD available at Vovlift?
Yes. It is in stock at Vovlift, an authorized Katool dealer.

Warranty

Authorized Katool Dealer

Full Manufacturer Warranty Included

Vovlift is a factory-authorized Katool dealer. Every machine ships brand-new with the complete manufacturer warranty and is backed by US-based support — so you are covered from day one.

1 Year

Parts & Defects Coverage

Optional

3 Years

Structural Components

*3-year structural coverage is an optional extension. 1-year parts & defects coverage is included as standard.

Documents

Katool KT-M140XD User Manual
